| main spec |
| Dimensions |
530 x 245 x 545 mm (DWH) |
| Form Factor |
Full Tower |
| Materials |
Steel + Plastic + Glass + Wood |
| Mainboard Support |
E-ATX (≤285mm), ATX, Micro-ATX, ITX |
| Front Access & Controls |
Power, Reset, USB 3.0 x 2, Type-C 10Gbps x 1, Headphone/Mic Combo Jack, Temp. Display Switch x 1 |
| Side Panel |
4mm Tempered Glass |
|
| Drive Bays |
| Expansion Slots |
8 |
| 3.5" /2.5" |
4/4 |
| 2.5" |
2 |
|
| Fan Support |
| Front |
3 x 120mm / 3 x 140mm |
| Top |
3 x 120mm / 3 x 140mm |
| Power Supply Shroud |
3 x 120mm |
| Bottom |
2 x 120mm / 2 x 140mm |
| Rear |
1 x 120mm / 1 x 140mm |
| Included Fan(s) |
3 x 140mm Tranquil PWM fans in front + 2 x 120mm P12R PWM reverse fans on PSU shroud
+ 1 x 140mm Tranquil PWM fan in rear |
|
| Radiator Support |
| Front |
120 / 140 / 240 / 280 / 360 / 420mm |
| Top |
120 / 140 / 240 / 280 / 360 / 420mm |
| Power Supply Shroud |
120 / 240 / 360mm |
| Bottom |
120 / 240mm |
| Rear |
120 / 140mm |
|
| Clearance |
| Max GPU Length |
≤ 455mm |
| Max CPU Cooler Height |
≤ 190mm |
| Max PSU Length |
(Include cable) ≤ 180 / 300mm (with HDD)
(Include cable) ≤ 470mm (without HDD)
(Not Include cable) ≤ 180mm (Side Mount) |
|
| Miscellaneous |
| Dust Filter |
Bottom |
| Net Weight |
13.60 Kg |
| Gross Weight |
16.65 Kg |
| Warranty |
2 Years |
|
