Jonsbo
Jonsbo Z20
Jonsbo Z20
Color:Black |
Dimension(w/o handle/feet and other protrusions):370mm * 186mm* 295mm(depth/width/height) |
(with handle/feet and other protrusions):382mm * 198mm* 335mm
(depth/width/height) |
Case Material:SPCC Steel,Tempered Glass |
Drive Bay: 2.5〞SSD:up to 3,depends on other hardware configurations 3.5〞HDD:up to 1,depends on other hardware configurations |
Front IO Port:USB3.2 Gen1 Type-A*1/USB3.2 Gen 2 Type-C*1/AUDIO*1 & MIC*1 |
FAN:Top:120mm*2/140mm*2;Rear:120mm*1/92mm*1; Bottom:120mm*2/140mm*2,depends on other hardware configurations |
Radiator support:Top,up to 240mm |
ATX PS2 PSU Clearance:Up to 180mm, recommended length ≤140mm,depends on other hardware configurations (Refer to page 11)
|
CPU Air Cooler Clearance:164mm MAX (Intel CPU) or 163mm MAX (AMD CPU) |
GPU Clearance:Up to 363mm,depends on other hardware configurations |
Weight:N.W. 5kg / G.W. 6.5kg |
